New Cable Management Kit (CM-F-ID) for Fanuc® 100iD Robots now available

As the speed and efficiency of modern production lines advances to meet productivity demands, cables connected to robots are an often overlooked cause of unnecessary downtime. Rigorous flexing and bending can cause cables to wear prematurely or even detach, bringing production to a halt.

WizardGear™ Robot Cable Management Products provide organization, support and protection for lines and cables attached to welding robots. Keep cables free from damage that can cause unnecessary downtime and costly repairs. Using zip ties or other poor methods of attachment can even void the warranty on control cables. Cable organizers are currently available for Fanuc® ARC Mate robots. Custom cable management solutions are available for other robot manufacturers. Kits including cables available with either 3/0 or 4/0 high performance welding cable. Click here for more information.

• Provides organization, support and protection for all lines and cables attached to robots
• Keep cables free from damage that can cause unnecessary downtime and costly repairs
• Allows full range of motion - does not hinder robot movement
• Approved by Fanuc® for securing & protecting control cables, other attachment methods may void warranty on cables
• Cable & Conduit Balancers, as well as Spatter-Resistant Cable Sleeves also available
• Custom cable management kits may be modified to fit other robot models

WizardGear® Conduit and Cable Balancers provide an easy method of hanging conduit and cables above areas where they are prone to damage. Excellent for robotic welding applications as well as submerged arc applications with manipulators. All models feature adjustable tension and heavy duty 8 ft nylon-jacketed braided steel cable. Balancers are available to handle workloads up to 27 lbs (12.2 kg).

WizardGear® Conduit Hangers prevent excess droopage in conduit that can cause excessive wire friction. Hangers feature heavy duty steel construction and Velcro straps to secure cables and conduit. Recommended accessory for conduit & cable balancers.

Swivel Kit and Guide Module installation example on the back of a feeder

There are a number of locations that can cause excess wire friction throughout the wire delivery system in robotic arc welding. The Wire Wizard® Guide Module System eliminates wire friction not only in stationary areas like over or through the weld cell wall, but it also can solve wire friction issues where there is a high degree of mobility at the back end of the wire feeder. This can be achieved by installing a Mini 90° Guide Module with a Wire Feeder Swivel Kit. The Guide Module includes a series of rollers to eliminate the friction around the bend, while the swivel kit includes heavy duty bearings that can twist and turn with the movement of the robot. This also increases the life of the conduit by taking the strain away from a sharp bend in the wire delivery system in robotic welding applications.

Wire Feeder Swivel Kits are available for direct connection to Lincoln Electric®, Panasonic® and OTC® wire feeders and may be adapted to others as well. Contact your Wire Wizard® Technical Sales expert for more information and for assistance with your wire delivery system setup.
